Name: EARLS Speed-Flex Hyperfirm® Pre-Made Hose - 64151512ERL
SKU: 64151512ERL_A
Availability: InStock

Description

Overview:

Our factory assembled hoses are made from the same SPEED-FLEX stainless steel braid protected hose of extruded PTFE that is the world standard of the racing industry for flexible brake, clutch and instrument hoses. Hoses are assembled with Earl”s SPEED-FLEX crimp or swaged permanently installed hose ends. Each hose is pressure tested to 4,000 psi.

Features:

Extruded PTFE
Standard Of Racing Industry
Firmer Brake Feel
For Flexible Brake & Clutch Hoses
For Instrument Hoses
Pressure Tested To 4000 PSI

Application:

Year	Make	Model	Submodel	Engine Size
Universal

Specs:

Brand	Earls
Emission Code	5
Fluid Type	Automatic Transmission Fluid
Fluid Type	Bio-Fuels
Fluid Type	Brake Fluid
Fluid Type	Coolant
Fluid Type	Diesel
Fluid Type	E85
Fluid Type	Methanol/Alcohol
Fluid Type	Oil
Fluid Type	Pump Gas
Fluid Type	Race Gas
Fluid Type Rating – Automatic Transmission Fluid	5 out of 5 Rating
Fluid Type Rating – Bio-Fuels	5 out of 5 Rating
Fluid Type Rating – Brake Fluid	5 out of 5 Rating
Fluid Type Rating – Coolant	5 out of 5 Rating
Fluid Type Rating – Diesel	5 out of 5 Rating
Fluid Type Rating – E85	5 out of 5 Rating
Fluid Type Rating – Methanol/Alcohol	5 out of 5 Rating
Fluid Type Rating – Oil	5 out of 5 Rating
Fluid Type Rating – Power Steering Fluid	5 out of 5 Rating
Fluid Type Rating – Pump Gas	5 out of 5 Rating
Fluid Type Rating – Race Gas	5 out of 5 Rating
Fluid Type Rating – Vacuum	1 out of 5 Rating
Hose End #1	1/8″ NPT MALE
Hose End #2	1/8″ NPT MALE
Hose End Finish	Electroless Nickel Plated
Hose End Material	Steel
Hose Outer Material	Stainless Steel
Hose Size	4 AN
Inside Diameter	.173″-.203″
Length	12 In.
Max Working PSI	2000 PSI
Min. Bend Radius	1.5″
Outside Diameter	.304″-.343″
Product Type	Hose Assembly
PTFE Wall Thickness	.040″
Submersible in Fuel	Yes
Temperature Range	-65° to 450° F
Warning	California Proposition 65
