Big Block Chevy 8 Crank Trigger Wheel, Black - 86213

Big Block Chevy 8 Crank Trigger Wheel, Black – 86213

Original price was: $340.15.Current price is: $102.05.

SKU: 86213_A Category: Tag:

Description

Overview:

For a long time, racers have known that one of the best things to do to an engine to improve its performance is to stabilize the ignition timing. The MSD Flying Magnet Crank Trigger systems do exactly that by using four magnets embedded in an aluminum wheel. Although similar in appearance to other crank triggers, the MSD Flying Magnet design works on a different principle. Most crank triggers have a wheel, with steel studs sticking out, bolted to the harmonic balancer. As the crankshaft turns, the studs pass by a stationary magnetic pick-up, triggering the ignition. This pick-up can be triggered by other bolts, debris or even vibrations which will cause a loss of power or engine damage. The MSD Flying Magnet Crank Trigger uses four magnets secured in the aluminum trigger wheel that pass by a stationary non-magnetic pick-up to trigger the ignition. This “”flying magnet”” design produces accurate trigger signals and the non-magnetic pick-up cannot be false triggered, making this one of the best on the market!!

Features:

Application:

Year Make Model Submodel Engine Size
1963 Chevrolet Bel Air 4.31/8 V
1963 Chevrolet Biscayne 4.31/8 V
1963 Chevrolet Impala 4.31/8 V
1965 – 1969 Chevrolet Bel Air 4.09/8 V
1965 – 1969 Chevrolet Biscayne 4.09/8 V
1965 – 1969 Chevrolet Chevelle 4.09/8 V
1965 Chevrolet Corvette 4.09/8 V
1965 – 1974 Chevrolet Impala U/K/8 V
1965 – 1969 Chevrolet Impala 4.09/8 V
1965 – 1967 Chevrolet Malibu 4.09/8 V
1965 – 1969 Pontiac Beaumont 4.09/8 V
1965 – 1969 Pontiac Strato-Chief 4.09/8 V
1966 – 1975 Chevrolet Bel Air 4.25/8 V
1966 – 1972 Chevrolet Biscayne 4.25/8 V
1966 – 1969 Chevrolet Caprice 4.09/8 V
1966 – 1976 Chevrolet Caprice 4.25/8 V
1966 – 1973 Chevrolet Chevelle U/K/8 V
1966 – 1974 Chevrolet Corvette 4.25/8 V
1966 – 1976 Chevrolet Impala 4.25/8 V
1966 – 1969 Pontiac Laurentian 4.09/8 V
1966 – 1969 Pontiac Parisienne 4.09/8 V
1967 – 1969 Chevrolet Camaro 4.09/8 V
1968 – 1974 Chevrolet Bel Air U/K/8 V
1968 – 1972 Chevrolet Biscayne U/K/8 V
1968 – 1974 Chevrolet C10 Pickup U/K/8 V
1968 – 1969 Chevrolet C10 Pickup 4.09/8 V
1968 – 1974 Chevrolet C20 Pickup U/K/8 V
1968 – 1969 Chevrolet C20 Pickup 4.09/8 V
1968 – 1974 Chevrolet C30 Pickup U/K/8 V
1968 – 1969 Chevrolet C30 Pickup 4.09/8 V
1968 – 1969 Chevrolet Camaro U/K/8 V
1968 – 1974 Chevrolet Caprice U/K/8 V
1968 Chevrolet Chevy II U/K/8 V
1968 Chevrolet Chevy II 4.09/8 V
1968 – 1974 Chevrolet Corvette U/K/8 V
1968 – 1974 Chevrolet K10 Pickup U/K/8 V
1968 – 1969 Chevrolet K10 Pickup 4.09/8 V
1968 – 1974 Chevrolet K20 Pickup U/K/8 V
1968 – 1969 Chevrolet K20 Pickup 4.09/8 V
1968 – 1974 Chevrolet K30 Pickup U/K/8 V
1968 – 1969 Chevrolet K30 Pickup 4.09/8 V
1968 – 1974 GMC C15/C1500 Pickup U/K/8 V
1968 – 1969 GMC C15/C1500 Pickup 4.09/8 V
1968 – 1974 GMC C25/C2500 Pickup U/K/8 V
1968 – 1969 GMC C25/C2500 Pickup 4.09/8 V
1968 – 1974 GMC C35/C3500 Pickup U/K/8 V
1968 – 1969 GMC C35/C3500 Pickup 4.09/8 V
1968 – 1969 GMC K15/K1500 Pickup U/K/8 V
1968 – 1969 GMC K15/K1500 Pickup 4.09/8 V
1968 – 1974 GMC K25/K2500 Pickup U/K/8 V
1968 – 1969 GMC K25/K2500 Pickup 4.09/8 V
1968 – 1974 GMC K35/K3500 Pickup U/K/8 V
1968 – 1969 GMC K35/K3500 Pickup 4.09/8 V
1968 – 1969 Pontiac Acadian 4.09/8 V
1969 Chevrolet Brookwood 4.09/8 V
1969 – 1972 Chevrolet Brookwood 4.25/8 V
1969 Chevrolet Camaro 4.25/8 V
1969 Chevrolet Estate 4.09/8 V
1969 – 1970 Chevrolet Estate 4.25/8 V
1969 Chevrolet Kingswood 4.09/8 V
1969 – 1972 Chevrolet Kingswood 4.25/8 V
1969 – 1970 Chevrolet Nova U/K/8 V
1969 Chevrolet Nova 4.09/8 V
1969 Chevrolet Townsman 4.09/8 V
1969 – 1972 Chevrolet Townsman 4.25/8 V
1970 – 1972 Chevrolet Bel Air 4.13/8 V
1970 – 1972 Chevrolet Biscayne 4.13/8 V
1970 – 1972 Chevrolet Brookwood 4.13/8 V
1970 – 1972 Chevrolet C10 Pickup 4.13/8 V
1970 – 1972 Chevrolet C20 Pickup 4.13/8 V
1970 – 1972 Chevrolet C30 Pickup 4.13/8 V
1970 – 1972 Chevrolet Camaro 4.13/8 V
1970 – 1972 Chevrolet Caprice 4.13/8 V
1970 – 1972 Chevrolet Chevelle 4.13/8 V
1970 – 1973 Chevrolet Chevelle 4.25/8 V
1970 Chevrolet Estate 4.13/8 V
1970 – 1972 Chevrolet Impala 4.13/8 V
1970 – 1972 Chevrolet K10 Pickup 4.13/8 V
1970 – 1972 Chevrolet K20 Pickup 4.13/8 V
1970 – 1972 Chevrolet K30 Pickup 4.13/8 V
1970 – 1972 Chevrolet Kingswood 4.13/8 V
1970 – 1972 Chevrolet Kingswood U/K/8 V
1970 – 1972 Chevrolet Monte Carlo 4.13/8 V
1970 – 1974 Chevrolet Monte Carlo U/K/8 V
1970 – 1975 Chevrolet Monte Carlo 4.25/8 V
1970 – 1972 Chevrolet Nova 4.13/8 V
1970 – 1971 Chevrolet Nova 4.25/8 V
1970 – 1972 Chevrolet Townsman 4.13/8 V
1970 – 1972 Chevrolet Townsman U/K/8 V
1970 – 1972 GMC C15/C1500 Pickup 4.13/8 V
1970 – 1972 GMC C25/C2500 Pickup 4.13/8 V
1970 – 1972 GMC C35/C3500 Pickup 4.13/8 V
1970 – 1972 GMC K15/K1500 Pickup 4.13/8 V
1970 – 1972 GMC K25/K2500 Pickup 4.13/8 V
1970 – 1972 GMC K35/K3500 Pickup 4.13/8 V
1970 – 1971 Pontiac Acadian 4.25/8 V
1970 Pontiac Laurentian 4.25/8 V
1970 Pontiac Parisienne 4.25/8 V
1970 Pontiac Strato-Chief 4.25/8 V
1973 – 1974 Chevrolet C10 Pickup 4.25/8 V
1973 – 1974 Chevrolet C20 Pickup 4.25/8 V
1973 – 1974 Chevrolet C30 Pickup 4.25/8 V
1973 – 1974 Chevrolet K10 Pickup 4.25/8 V
1973 – 1974 Chevrolet K20 Pickup 4.25/8 V
1973 – 1974 Chevrolet K30 Pickup 4.25/8 V
1973 – 1974 Chevrolet Laguna U/K/8 V
1973 – 1975 Chevrolet Laguna 4.25/8 V
1973 – 1974 Chevrolet Malibu U/K/8 V
1973 – 1975 Chevrolet Malibu 4.25/8 V
1973 – 1974 GMC C15/C1500 Pickup 4.25/8 V
1973 – 1974 GMC C25/C2500 Pickup 4.25/8 V
1973 – 1974 GMC C35/C3500 Pickup 4.25/8 V
1973 – 1974 GMC K15/K1500 Pickup 4.25/8 V
1973 – 1974 GMC K25/K2500 Pickup 4.25/8 V
1973 – 1974 GMC K35/K3500 Pickup 4.25/8 V
1975 – 1980 Chevrolet C10 4.25/8 V
1975 – 1985 Chevrolet C20 4.25/8 V
1975 – 1985 Chevrolet C30 4.25/8 V
1975 – 1978 GMC C15 4.25/8 V
1975 – 1978 GMC C25 4.25/8 V
1975 – 1978 GMC C35 4.25/8 V
1976 – 1980 Chevrolet K10 4.25/8 V
1976 – 1978 Chevrolet K20 4.25/8 V
1976 GMC K15 4.25/8 V
1976 – 1978 GMC K25 4.25/8 V
1977 – 1985 Chevrolet K30 4.25/8 V
1979 – 1980 GMC C1500 4.25/8 V
1979 – 1985 GMC C2500 4.25/8 V
1979 – 1985 GMC C3500 4.25/8 V
1979 – 1985 GMC K3500 4.25/8 V
1980 GMC K1500 4.25/8 V

Specs:

Brand MSD
Color Black
Diameter 8″”
Emission Code 4
Make Chevy
Product Type Crank Trigger Wheel
Sensor Dimensions 3/4″” x 2.25″”
Sensor Type Non Magnetic
Trigger Type 4X
Warning California Proposition 65
Warranty Limited 1 Year Warranty
Wheel Width 3/8″”
